Core Veneer Plywood Dryer

Category：

Roller Core Veneer Dryer
Brand：

SHINE
Browse number：

10128
Release time：

2019-07-30 11:04:07
E-mail:info@sdshinemachinery.com

Detailed Description
Attributes

Core Veneer Plywood Dryer Introduction

The core veneer plywood dryer produced by Shandong Shine Machinery Co., Ltd. is widely used in flatting drying of high-grade plywood, multi layer board and architectural core face veneer.the timber core veneer plywood dryer is equipped with environmental protection type hot air stove. its characteristics: save fuel, twice use of hot air , increase heating speed.the veneer after drying is flat,moisture content is up to national standard. Equipped with integral type high efficiency energy saving hot air stove. No boiler and other auxiliary equipment, no use water,coal, electricity. Rind ,wood chips and wood craps are all can be as fuel. and can quickly achieve the heat required by the timber core veneer plywood dryer.Roller Veneer dryer is one of the main equipment in plate production.

core veneer dryer

Main Technical Parameter For Core Veneer Plywood Dryer

Parameter Model	DHS20M	DHS24M	DHS28M	DHS32M	DHS36M	DHS40M
Work width（m）	3	3	3	3	3	3
Deck	1	1	1	1	1	1
Veneer thickness（mm）	0.5-5	0.5-5	0.5-5	0.5-5	0.5-5	0.5-5
Heating area （m）	16	20	24	28	32	36
Cooling area (m)	4	4	4	4	4	4
Initial water content(%)	50-80	50-80	50-80	50-80	50-80	50-80
Finished water content(%)	10	10	10	10	10	10
Drying capacity (m³/h)	0.5-0.65	0.65-0.8	0.8-1	1-1.2	1.15-1.35	1.3-1.5
Heat exhaustion（10000 kcal）	17.5-23	23-285	28-35	35-42	40.25-47.25	45.5-52.5
Traction motor power(kw)	7.5	7.5	5.5	5.5	5.5	5.5
Hot air fan power (kw)	7.5*4	7.5*5	7.5*6	7.5*7	7.5*8	7.5*9
Air cooling fan power（kw）	7.5	7.5	7.5	7.5	7.5	7.5
Total power (kw)	45	52.5	58	65.5	73	80.5
Overall size LxWxH（m）	20*4.5	24*4.5	28*4.5	32*4.5	36*4.5	40*4.5

Parameter Model	DHS44M	DHS48M	DHS52M	DHS56M	DHS60M
Work width（m）	3	3	3	3	3
Deck	1	1	1	1	1
Veneer thickness（mm）	0.5-5	0.5-5	0.5-5	0.5-5	0.5-5
Heating area （m）	40	44	44	48	52
Cooling area (m)	4	4	4+4	4+4	4+4
Initial water content(%)	50-80	50-80	50-80	50-80	50-80
Finished water content(%)	10	10	10	10	10
Drying capacity (m³/h)	1.5-1.7	1.65-1.8	1.7-1.9	1.8-2	1.9-2.2
Heat exhaustion（10000 kcal）	52.5-59.5	57.75-63	59.5-66.5	63-70	66.5-77
Traction motor power(kw)	5.5	7.5	7.5	7.5	7.5
Hot air fan power (kw)	7.5*10	7.5*11	7.5*11	7.5*12	7.5*13
Air cooling fan power（kw）	7.5	7.5	7.5*2	7.5*2	7.5*2
Total power (kw)	88	97.5	105	112.5	120
Overall size LxWxH（m）	44*4.5	48*4.5	52*4.5	56*4.5	60*4.5

Company Profile

The Shine Machinery production workshop is equipped with internationally advanced CNC machining equipment and precision testing instruments. From the processing of core components to the assembly and debugging of the entire machine, a strict standardized production process has been established.

factory

FAQ

1. Q: Are you a factory or a trading company?

A: We are a factory who manufacture the machine by ourselves.

2. Q: What is the delivery time?

A: Normally will be 30 days after getting deposit or original LC.

3. Q: What is the maintenance period? What kinds of after-sale service do you support?

A: 1 year after delivery. We supply telephone after-sale service, video service and e-mail service. If can not deal with the problem, our tech-staff will go abroad to service.

4. Q:What is the payment terms?

A:a.T/T(30% deposit, 70% before delivery in FOB or 70% paid against copy of B/L in CFR)

b. 100% irrevocable L/C at sight.

5. Q: Can we visit your factory?

A: Welcome to visit us! Everyday we have customers from different countries. By now, we have exported to more than 50 countries customer.

Certification： CE;ISO

Veneer Thickness： 0.5~5mm
