Veneer Dryer For Hot Sale

Category：

Biomass Roller Veneer Dryer
Brand：

SHINE
Browse number：

932
Release time：

2024-10-08 16:07:06
E-mail:info@sdshinemachinery.com

Detailed Description

Shine veneer dryer provides you with a one-stop solution. The dried veneer has uniform moisture content, is flat, has no wrinkles or end ripples, no cracks, and has a good surface glued state. The power of the whole machine is reduced by 38%, and the power consumption is greatly reduced compared with the traditional veneer dryer.

veneer dryer.jpg

Working principle of Veneer Dryer

The veneer dryer is driven by the chain to run the upper and lower rollers, relying on the upper roller to press the veneer to run. Biomass combustion furnace is used to burn wood chips, waste wood and other materials at high temperature. Materials boil and fluidize in the burner to provide heat energy to the veneer dryer.For process the surface veneer and long core veneer, this veneer dryer can avoid the break of the veneer, then can raise the veneer utilization ratio and production output.

veneer dryer.jpg

Product Parameters of Veneer Dryer

Wood species	Veneer Drying capacity (m³/h)				Veneer water moisture	Veneer thickness and size
	1 deck veneer dryer	2 deck veneer dryer	4 deck veneer dryer	6 deck veneer dryer
Eucalyptus	0.5-2	1-3.3	2-9.0	15-17	Fresh Veneers (above 70%) to about 0-10%	0.8-8mm
Birch	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 70%) to about 0-10%	0.8-8mm
Rubberwood	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 60%) to about 0%	0.8-8mm
Poplar	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 50%) to about 0-10%	0.8-8mm
Beech	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 70%) to about 0-10%	0.8-8mm
Pine	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 70%) to about 0-10%	0.8-8mm
Other	0.6-2.2	1.2-3.8	2.3-10	15-18	Fresh Veneers (above 70%) to about 0-10%	0.8-8mm
shine veneer dryer can dry various types of wood. If you want to know more detailed information, please feel free to contact us!
